Home  >  Terminal Blocks  >  Pluggable Terminal Block  >  FPC2.5-XX-508-08
PCB Pluggable Terminal Block Alternative | Compact Housing Structure | FPC2.5-XX-508-08

PCB Pluggable Terminal Block Alternative Compact Housing Structure

Rated current:20A

Rated voltage （III/2）:320V

pitch:5.08mm

Add to quote

Product certification

Replacement Compatibility

  • Compatible with: Phoenix Contact: MSTBT-2.5-ST
  • Alternative to: Dinkle: 5ESDT, 2EDGKF

Product Advantages

  • ☑ Compact 5.0mm pitch saves valuable board space.
  • ☑ T-type design with side wire entry.
  • ☑ Robust housing for durability in industrial environments.

Application Scenarios

  • High-density wiring cabinets
  • Automation equipment
  • Power distribution units

Connection capacity

Conductor cross section solid 0.2~2.5mm²
Conductor cross section flexible 0.2~2.5mm²
AWG 28~12AWG
Torque 0.5N.m
Strip length 7mm





Electrical parameters UL

Rated voltage (B) 300V
Rated voltage (D) 300V
Rated current (B) 15A
Rated current (D) 10A





Electrical parameters lEC

Rated voltage 320V
Rated current 20A
Rated voltage(III/2) 320V
Rated surge voltage(III/2) 4KV





ltem properties

Connection direction 0°
Connection method Screw connection
Screwdriver Slotted screwdriver
screw thread M3
Pitch 5.08mm
Number of potentials 2-12P
Pluggable or not Yes
Number of rows 1





Material data

Environmental items Compliant with REACH/RoHS
Contact material Copper alloy
Contact point metal surface tin-plated
Contact zone metal surface tin-plated
Insulation Materials PA66
Insulating material group Ⅰ
Flammability rating UL94V-0





Mechanical tests

Test Specification IEC61984/ UL1059





Environmental data

Ambient temperature (operation) -40℃~105℃(depending on derating curve)



Brand AOSI
Packing unit 100
Minimum order quantity 50
Products weight(g):
02P 3.25
03P 4.90625
04P 6.5416666666667
05P 8.1818181818182
06P 9.8076923076923
07P 11.467391304348
08P 13.101265822785
09P 14.714285714286
10P 16.357142857143
12P 19.71
13P 23.18
18P 31.17
FPC2.5-XX-508-08AOSI.pdf
PDF Download
