Male Plug in Terminal Block | Panel Mount SuPort | FPC4-XX-762-00

Home > Terminal Blocks > Pluggable Terminal Block > FPC4-XX-762-00

Male Plug in Terminal Block Panel Mount SuPort

Rated current:30A
Rated voltage（III/2）:300V
pitch:7.62mm
Color:green
Contact surface :Tin

Model

Position

AOSI Electronics is a professional manufacturer of terminal blocks and modules, offering reliable connection solutions for industrial automation, new energy, and electrical systems.

Connection capacity

Conductor cross section solid	0.2~10mm²
Conductor cross section flexible	0.2~10mm²
AWG	24~8AWG
Strip length	14mm

Electrical parameters UL

Rated voltage (B)	600V
Rated voltage (C)	600V
Rated current (B)	35A

Electrical parameters lEC

Rated voltage	1000V
Rated voltage(III/3)	1000V
Rated current	41A
Rated voltage(III/2)	1000V
Rated voltage(II/2)	1000V
Rated surge voltage(III/3)	8KV
Rated surge voltage(III/2)	8KV
Rated surge voltage(II/2)	6KV

ltem properties

Connection direction	0°
Connection method	Push-in spring connection
Pitch	7.62mm
Number of potentials	2-12P
Pluggable or not	Yes
Number of rows	1

Material data

Contact material	copper
Contact point metal surface	tin-plated
Contact zone metal surface	tin-plated
Insulation Materials	PA66
Shell color	green
Insulating material group	Ⅰ
Flammability rating	UL94V-0

Mechanical tests

Test Specification

IEC61984/ UL1059

Environmental data

Relative humidity (storage/transport)	30% ~ 70%
Ambient temperature (assembly)	-5℃~100℃
Ambient temperature (operation)	-40℃~105℃(depending on derating curve)
Ambient temperature (storage / transport)	-40℃~70℃

Packing unit	500
MOQ	30
Weight (without packaging)

VDE parameters

Overvoltage category/pollution level	III/3	III/2	II/2
Rated voltage	/	/	/
Rated current	/	/	/
Wiring capacity	/	/	/

UL parameters

Application category	B	C	D
Rated voltage	600	600	/
Rated current	35	35	/
AWG	/	/	/

FPC4-XX-762-00AOSI.pdf
