Home  >  Terminal Blocks  >  Pluggable Terminal Block  >  FPH1.5-XX-350-29
Pluggable Terminal Block alternative to Phoenix Contact | Right Angle Solder Legs | FPH1.5-XX-350-29

Pluggable Terminal Block alternative to Phoenix Contact Right Angle Solder Legs

Rated current:8A.Rated voltage ???a???/2???:300V,Cross section:1.0mm?2,pitch:3.5mm,Color:black,Contact surface :Tin

Add to quote

Product certification

Replacement Compatibility

  • Series Description: 3.5mm pitch Shrouded Header (Vertical with Latches)
  • Alternative Models: 15EDGVHDM

Product Advantages

  • ☑ Locking latches on the side provide a secure connection that resists shock and vibration.
  • ☑ Shrouded design protects pins and ensures proper plug orientation.
  • ☑ A step-up in reliability from standard unshrouded headers.

Application Scenarios

  • High-vibration environments
  • Automotive electronics
  • Field-based control units


Electrical parameters UL

Rated voltage (B) 150V
Rated current (B) 10A
Rated current (C) 10A
50A





Electrical parameters lEC

Rated voltage 200V
Rated voltage(III/3) 80V
Rated current 10A
Rated voltage(III/2) 200V
Rated voltage(II/2) 320V
Rated surge voltage(III/3) 2.5KV
Rated surge voltage(III/2) 2.5KV
Rated surge voltage(II/2) 2.5KV





ltem properties

Connection direction 90°
Type of installation PCB welding
Pin arrangement Double-row in a straight line
Pitch 3.5mm
Number of potentials 2-12P
Number of rows 2





Material data

Environmental items Compliant with REACH/RoHS
Contact material copper
Contact zone metal surface tin-plated
Insulation Materials High temperature resistant materials
Shell color Black
Insulating material group Ⅲa
Flammability rating UL94V-0





Mechanical tests

Ambient temperature (operation) -30℃~120℃(depending on derating curve)



Brand AOSI
Packing unit 100
Minimum order quantity 50
Products weight(g):
04P 2.21
06P 2.61
08P 3.02
10P 3.42
12P 3.82
14P 4.23
16P 4.63
18P 5.03
20P 5.44
22P 5.84
24P 6.24
26P 6.64
28P 7.05
30P 7.45
32P 7.86
34P 8.26
36P 8.66
38P 9.06
40P 9.47
42P 9.87
44P 10.27
46P 10.68
FPH1.5-XX-350-29AOSI.pdf
PDF Download
